不锈钢美标闸阀

类型 不锈钢闸阀


特征
-1/2"~12"(DN15-'DN300)
-工作压力 W.P.: CLASS 150/300
-工作温度 W.T.: -20°C~180°C
-升杆式/明杆Rising stem
-设计标准Design:ASME B16.34
-法兰标准Flange dimension: ASME B16.5
-结构长度 Favetoface: ASMEB16.10
-检验&测试 Inspection &testing : API 598

材料列表

序号NO.零件名称PARTS材届 MATERIAL
1阀体BODYWCB-M3CrCF8CF8M
2闸板DISCWCB+13CrCF8CF8M
3阀杆STEM20C「13304316
4垫片GASKETPTFE/304+石墨 GPAPHITE
5阀盖BONNETWCRCF8CF8M
6螺柱BOLT35C「M〇304304
7螺母NUT45304304
8填料 PACKINGPTFE+柔性石墨 GPAPHITE
9销轴CLEVIS PIN WITH HEAD35304304
10开□消 SPLIT PINQ235A304304
11压盖 NUT GLANDWCRCF8CF8
12活节螺栓EYE BOLTS35CrMo304304
13平垫 FLATPAO65Mn304304
14摞母MUT45304304
15阀杆螺母BONNETNUT青铜BRONZE
16阀盖BONNET45 304304
17手 HANDLEELFCD/WCB
18圓螺母NOUNDNUT45304304


Z13 美标 ANSI CLASS 150

尺寸sizeLdD2D1Dbfn —a>d1HW
151/2"108153560.3901024-161 78120
203/4"11720437010010.524-16194120
251"127255179.411010.524-16223140
321-1/4"1403263.588.911511.224-16266160
401-1/2"165407398.412512.724-16295160
502"1 785092120.715014.324-19336200
652-1/2"19065105139.718015.924-19385200
BO3"203BO12715?.419017.524-19433250
1004"229100157190.523022.328-19506300
1255"25412518521625522.328-22612300
1506"267150216241.328023.928-22686350
2008"292200270298.53452728-22825350
?5010"330P503P436?405PB.621P-P597P400
30012"356300381431.848530.2212-251147450


Z17 美标 ANSI CLASS300

尺寸sizeLdD2D1Dbfn —a>d1HW
151/2"140153566.79512.724-16182120
?03/4"15??0438?.611514.3?4-19197140
251"165255188.912515.924-19229160
321-1/4"1783263.598.413517.524-19271160
401-1/2"1904073114.315519.124-22299200
502"216509212716520.728-19343200
652-1/2"24165105149.219023.928-22392250
803"28280127168.32102728-22443300
1004"30510015720025530.228-22515300
1255"38112518523528033.428-22624350
1506"40315021627032035212-22695350
2008"419200270330.238039.7212-25842400
25010"4572503?4387.444546.1216-29989450
30012"502300381450.852049.3216-321158500
